Buckeye BFR-SC-100 shielded cable is stainless steel cable in a flexible sheath for the mechanical functions of the Buckeye Kitchen Mister kitchen fire suppression system. The cable connects the detection line, the mechanical gas valve or the manual pull station to the release unit, while the sheath guides and protects the cable along the run.

• Model: BFR-SC-100, Buckeye part no. BFRSC100
• Stainless steel cable, 1/16" (approx. 1.6 mm)
• Approx. 32 m (105 ft) of sheath and 64 m (210 ft) of cable in the pack
• Connection with the BFR-SCI adapter to 1/2" EMT fittings and corner pulleys

The cable run must stay within the manual's limits for length and number of bends. Installation and function testing are carried out by an authorised Buckeye installer in accordance with the BFR-TM technical manual, checking that the cable moves freely and the sheath is correctly anchored.

Cable, sheath and connections are checked at the service, at least every six months.

Buckeye BFR-5K is a complete system package for fixed fire protection of commercial kitchens and restaurants, with a capacity of up to 5 flow points. The Kitchen Mister system discharges a wet chemical agent through fixed nozzles over cooking appliances, hood plenums and exhaust ducts. The agent cools the fire and helps prevent re-ignition of grease and oil.

• System package BFR-5K with pre-filled, pressurised BFR-5 cylinder
• Capacity: max. 5 flow points
• Agent: potassium carbonate based wet chemical
• Propellant: nitrogen, 13.44 bar (195 psi) at 21 °C
• Automatic actuation with fusible links and manual actuation – mechanical, no power required
• Operating temperature 0 to +49 °C, indoors
• Cylinder approx. 630 x 250 mm (height x diameter), approx. 19 kg, bracket MB-1
• UL 300 listed and CE marked

Nozzles, piping and actuation are tailored to the kitchen. The system is designed and installed by an authorised Buckeye installer in accordance with the BFR-TM technical manual, and the cylinder is mounted upright.

The owner inspects and records the system every month. Service is carried out at least every six months by an authorised Buckeye technician, and after a discharge the cylinder must be recharged and the system reset.

ExiLED 25m HC pictogram kit is a replaceable set of high-contrast (HC) pictograms for the Honeywell ExiLED 25m exit sign luminaire. The kit lets you change the direction shown on the luminaire – for example after refurbishment or a changed escape route – without replacing the luminaire itself.

• Honeywell part no. 138080.2
• Fits ExiLED 25m exit sign luminaire (Honeywell part no. 138087)
• 7 pictograms: 2N, 2O, HV and blank plate
• For single-sided and double-sided mounting
• High contrast (HC) for good legibility
• Viewing distance 25 m
• Ordered separately from the luminaire

The correct pictogram is essential for the exit sign to show the escape direction clearly. Check that the pictograms match the evacuation plan after changes to the building and during periodic inspection of the emergency lighting.
